  1. Last week
  2. Would you kindly advise me on the finest mobile to use while wearing a formal shirt? It can enhance my appearance and go well with my personality.
  3. Thanks, good to know I was barking up the wrong tree. For years I have been debugging using JTAG probes. Usually on Kinetis parts using their own hacked up version of eclipse. I am new to the openDCD and raw GDB debugging. But all the documentation makes it look easy once i get the JTAG thing up and going. Tomorrow I will have an new tree to bark at. Thanks for your help Dave
  4. Yes, the two serial ports are correct. Yes, this is most likely the issue. You need an ELF file. Then you can start up gdb and point to the elf file: You start gdb and point to the elf file: arm-none-eabi-gdb 'elf file you want to flash' Now from GDB, you can connect to an attached device. Attach the JTAG cable to the target. But you need to tell GDB where to go, so let's point it to the serial port: target extended-remote /dev/cu.usbmodemJEFF1 (I'm not sure what the destination is on windows, but replace /dev/cu....) Then tell the probe what kind of JTAG you want to use, probably 2 wire serial: monitor swdp_scan Assuming you see the target, you can attach to it: attach 1 Then you can load the file: load You can now walk through and step through various aspects of code, assuming the elf file has debug symbols in it. We're going to start diving into advanced firmware topics, and I'm not sure your experience. Here is the documentation, for the same product the firmware is derived from: https://github.com/blackmagic-debug/blackmagic They have a lot of documentation, and a wiki to get started.
  5. HI Jason, I have flashed both of my devices to: Black Magic Probe (SAMD2), (Firmware v1.6.2-5-gca7bf01) I still see 2 serial ports at 6018 none at 6017. When I hold the switch down to put it in bootloader mode, I see a single device at 6017, but that is useless for debugging. Is this the correct firmware now? Am I misunderstanding how this thing is supposed to work? Thanks Dave
  6. Earlier
  7. I just got my second one in. As expected it has the same problem. One difference was when I first plugged it in to the Windows 10 machine it did a little dance and acted like it might have updated the firmware but no, It has the same problem. It's been a while since i did an substantial Linux stuff. the only operating Linux machine I have is a raspberry pi. I tried but for me that is a giant pain. How about I mail you both of the devices and you can update them for me? Hopefully Dave
  8. I think it's because you need to have the windows driver installed. Or re-run as an administrator. Windows is a piece of dog shit for stuff like this. This is why all my products use HID and all my apps can talk to them driverless. Because I'm 100% done with drivers in windows. I've spent enough time on the phone helping people with 'unknown device' in device manager trying to force install my own drivers.
  9. Everything works better in the morning. Ill try again then. You have been awesome!
  10. Ok i have it up in DFU Demo mode. It does show a PID of 1d50:6017, But alas :: Invalid DFU suffix signature A valid DFU suffix will be required in a future dfu-util release!!! Cannot open DFU device 1d50:6017 No DFU capable USB device available
  11. You can let go of the button after you plug it in after waiting a second or two. You should see a different usb product ID show up. PID_6018 for the main app PID_6017 for the DFU I think you need the driver installed for both in windows. If you have linux, you might have an easier time.
  12. i dont understand (just to be clear).. Unplug the device, Push the button, Plug it in while holding the button. continue holding the button while executing the command?
  13. I just ordered another one from amazon. Delivery tomorrow.
  14. No you can't pop it. maybe it's not in the bootloader. Hold down the button when you plug it in.
  15. PS C:\Esp\frameworks\esp-idf-v4.4.1> dfu-util --device ,1d50:6017 -s 0x00002000:leave -D C:\Users\dave\Downloads\blackmagic-master\blackmagic-master\src\blackmagic.bin dfu-util 0.9 Copyright 2005-2009 Weston Schmidt, Harald Welte and OpenMoko Inc. Copyright 2010-2016 Tormod Volden and Stefan Schmidt This program is Free Software and has ABSOLUTELY NO WARRANTY Please report bugs to http://sourceforge.net/p/dfu-util/tickets/ Invalid DFU suffix signature A valid DFU suffix will be required in a future dfu-util release!!! No DFU capable USB device available I don't think it likes me anymore. I get the same response if I try the 6018 PID. If I've popped it I dont mind buying another one. Thanks for getting back to me!!
  16. dfu-util --device ,1d50:6017 -s 0x00002000:leave -D src/blackmagic.bin try this
  17. I realized I never formally downloaded the Blackmagic-master. so I just ran the script and this happened: PS C:\Esp\frameworks\esp-idf-v4.4.1> dfu-util -d 1d50:6018,1d50:6017 -s0x02000:leave -D C:\Users\dave\Downloads\blackmagic-master\blackmagic-master\src\blackmagic.bin dfu-util 0.9 Copyright 2005-2009 Weston Schmidt, Harald Welte and OpenMoko Inc. Copyright 2010-2016 Tormod Volden and Stefan Schmidt This program is Free Software and has ABSOLUTELY NO WARRANTY Please report bugs to http://sourceforge.net/p/dfu-util/tickets/ Invalid DFU suffix signature A valid DFU suffix will be required in a future dfu-util release!!! Opening DFU capable USB device... ID 1d50:6018 Run-time device DFU version 011a Claiming USB DFU Runtime Interface... Determining device status: state = appIDLE, status = 0 Device really in Runtime Mode, send DFU detach request... Device will detach and reattach... Cannot open DFU device 1d50:6017 Lost device after RESET? PS C:\Esp\frameworks\esp-idf-v4.4.1> It did something but still both PIDs are 6018 and version v1.6.2
  18. Hi Jason, I got one of these jeff probe blackmagic JTAG clone from Amazon. I intend to use it on the ESP32-s2 chip using eclipse. I am running windows 11. When i look at it in the device manager it looks like two com ports. They both have the same PID 6018. I think when it is working correctly it should show 6017 (for the JTAG side) and 6018 for the UART side. The second port does not seem to work as a UART and of course the JTAG is a non starter. So I suspect I need to flash it with some new firmware. I tried the sketchy and scary Zadig jive it times out on both the Win11 and Win10. I have So after too much (but likely not enough info).. How do I flash the part? or should I just pack it in and go another route?
  19. I am also want to know more about this for the project of astroworld apparel.
  20. Will Raspbee II fit into a Raspberry 4 Flirc case?
  21. I am trying to build the SDK on an M1 MacMini 2020 adn here is the results I am getting: xx@tvs-Mac-mini cli % make flirc_util [BUILDING] flirc_util.debug [CC] src/main.c [CC] src/prepost.c [CC] lib/logging.c [CC] lib/getline.c [CC] lib/dict.c [CC] lib/cmds.c [CC] lib/cmds_script.c [CC] lib/cmds_shell.c [CC] src/cmds/version.c [CC] src/cmds/flirc_cmds.c [CC] src/cmds/ir_transmit.c [LINK] buildresults/Darwin_arm64/cc/flirc_util/debug/flirc_util ld: warning: directory not found for option '-L../libs/Darwin_arm64/' ld: library not found for -lflirc clang: error: linker command failed with exit code 1 (use -v to see invocation) make[2]: *** [buildresults/Darwin_arm64/cc/flirc_util/debug/flirc_util] Error 1 make[1]: *** [debug] Error 2 make: *** [flirc_util] Error 2 I guess the Darwin_arm64 version of the library doesn't exist. I was wondering if there are any work arounds for this.
  22. My ThinkPad T410 stalls at the first BIOS screen, until I remove my Flirc 2. My T420 boots fine with it. I tried disabling all USB device types from the boot order but that didn't help. Any Ideas? Thanks
  23. I am also facing same issue. Please help me about it quickly because I want to secure my important juice wrld clothes data which is saved in USB.
  24. Mobile App for E-commerce Stores Inside the setting of expanding on the web deals, the online business industry is seeing the main development of portable arrangements advancement directed by the need to fulfill client wants. Shoppers require the opportunity to buy labor and products whenever and from anyplace, even in a hurry. Subsequently, more internet based customers favor portable online business applications to sites, as they offer progressed speed, accommodation and versatility. How might retail organizations that are carrying on with work in the advanced space benefit from versatile applications? Magento 2 Mobile App Builder We grow strong eCommerce arrangements that convey effective outcomes Take your business from E-Commerce to M-Commerce With the send off of the App Store and Android Market (by and by Google Play) in 2008, the versatile application improvement market has turned into a prosperous specialty, bringing about the fast increment of accessible applications. Benefits of Mobile App for your Ecommerce Store. Deliver an amazing mobile experience Convert more customers Facilitate deeper customer relationships Ready to build your Ecommerce app?
  25. Was this ever fixed? I'm trying to map KEY_RECORD (167) to the Record button my remote. Using "flirc_util record_api 0 167" results in "Successfully recorded button" but when I check with evtest I don't get anything when I press it.
  26. oh yeah, 15 hour days, 7 days a week. We're going to announce and release it soon. It's this: https://flirc.tv/pages/teaser1140
  27. Are you still deep in "that other product"? ^^
